Multi-station CNC Integrated Machining Center
Quartering high-precision dividing plate is selected to drive the rotary table. A number of NC machining mechanisms are distributed over the rotary table to realize different procedures for the products at different stations, such as: external turning, internal turning, screw threading, tapping, grooving, milling end surfaces, drilling holes, etc.

Technical Parameters :

Voltages3P 380V, 1P 220V
Voltages Tolerance±10%
Air Pressure0.5 - 0.8Mpa
Size2820X2000X2100mm

Features and characteristics :

Quartering high-precision dividing plate is selected to drive the rotary table. A number of NC machining mechanisms are distributed over the rotary table to realize different procedures for the products at different stations, such as: external turning, internal turning, screw threading, tapping, grooving, milling end surfaces, drilling holes, etc.


Engineer Drawings :


Video :
